Conjugate Gradient Method

Concept

the first part is same as Steepest Descent Method, but after find the new $x$, we calculate next $g$ instead of finding steepest descent by

$$\beta =\frac{g_1^T{g}_1}{g_0^T{g}_0}$$

and

$$s_1=-g_1+\beta s_0$$

x0 = initial guess
g0 = \nabla f(x0)
s0 = g0
for k = 0, 1, 2,...
	Choose αk to minimize f(xk + αk sk)
	xk+1 = xk + αk sk
	gk+1 = \nabla f(xk+1)
	βk+1 = (g^Tk+1 gk+1)/(g^Tk gk)
	sk+1 = gk+1 + βk+1sk
end

Conjugate Gradient Method is only different with Steepest Descent Method with $\beta$, if we set $\beta$ constantly equal to $0$, it will be same as Steepest Descent Method.

Cost

unlike Newton’s method, this one doesn’t need to calculate Hessian matrix $H$ nor $b$, it only need to calculate gradient $\nabla$ and line search.

Code

import numpy as np
from typing import Callable, Tuple

def backtracking_line_search(
	f: Callable[[np.ndarray], float],
	grad_f: Callable[[np.ndarray], np.ndarray],
	x: np.ndarray,
	d: np.ndarray, # direction, usually - \nabla grad_f
	alpha_init: float = 1.0,
	rho: float = 0.5, # back trace factor
	c: float = 1e-4 # Armijo cond
) -> float:
	alpha = alpha_init
	f_x = f(x)
	grad_dot_d = np.dot(grad_f(x), d) # \nabla f(x)^Td

	# Armijo cond: f(x + α*d) \leqd f(x) + c*α* \nabla f(x)^Td
	while f(x + alpha * d) > f_x + c * alpha * grad_dot_d:
		alpha *= rho # backtrace

	return alpha

def conjugate_gradient(
    f: Callable[[np.ndarray], float],
    grad_f: Callable[[np.ndarray], np.ndarray],
    x0: np.ndarray,
    max_iter: int = 1000,
    tol: float = 1e-6
) -> Tuple[np.ndarray, float, int]:
	x = x0.copy()
	n = len(x)

	g = grad_f(x)
	d = -g.copy()

	iterations = 0

	for i in range(max_iter):
		if np.linalg.norm(g) < tol:
			break

		alpha = backtracking_line_search(f, grad_f, x, d)
		x_new = x + alpha * d
		g_new = grad_f(x_new)
		beta = np.dot(g_new, g_new) / np.dot(g, g)
		d = -g_new + beta * d
		x = x_new
		g = g_new

		iterations += 1

		# reset direction
		if (i + 1) % n == 0:
			d = -g.copy()

	return x, f(x), iterations
